Broadband Laser Mirrors

Custom and
Volume Manufacturing

Learn More

Filter
Broadband Dielectric ZERODUR® λ/10 Mirrors Broadband Dielectric ZERODUR® λ/10 Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • ZERODUR® Substrates Provide Near Zero Thermal Expansion
  • Enhanced Reflectivity and LDT over Metallic Coatings
  • UV, Visible, and NIR Reflective Coatings Designed for 0-45° AOI
  • Metallic Coated ZERODUR® Mirrors Also Available
Ultrafast-Enhanced Silver Coated Off-Axis Parabolic (OAP) Mirrors Ultrafast-Enhanced Silver Coated Off-Axis Parabolic (OAP) Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • Ultrafast-Enhanced Silver Coating for Ti:sapphire and Yb:doped Lasers
  • Low Group Delay Dispersion
  • <50Å RMS Surface Roughness to Minimize Scatter
UltraFast Innovations (UFI) High-Power Low-Loss Laser Mirrors UltraFast Innovations (UFI) High-Power Low-Loss Laser Mirrors
  • >99.99% Reflectivity at 1030nm and 1064nm
  • Laser Damage Threshold of 50 J/cm2 at 1064nm, 100Hz, 8ns
  • Universal Designs for Nanosecond, Picosecond, and Femtosecond Laser Pulses
  • Custom Options are Available up to 200mm Diameter
UltraFast Innovations (UFI) Ultra-Broadband Complementary Chirped Mirror Pairs UltraFast Innovations (UFI) Ultra-Broadband Complementary Chirped Mirror Pairs
  • Ideal for Chirped-Pulse Amplifier Systems and Ultra-Broadband Laser Oscillators
  • Ultra-Broadband Design Supports Dispersion Compensation
  • Negative GDD as Low as -60fs2 and High Reflectivity (>99%) at 600 – 950nm or 650 – 1350nm
TECHSPEC® Ultrafast-Enhanced Silver Concave Laser Mirrors Ultrafast-Enhanced Silver Concave Laser Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • Ideal for Focusing Ti:sapphire and Yb:doped Laser Pulses
  • Reflectivity >99% at 600 – 1000nm or 800 – 1150nm
  • Low Group Delay Dispersion as Low as 0 ±20fs2
  • Effective Focal Lengths from 25 to 500mm
  • TECHSPEC® Ultrafast-Enhanced Silver Laser Mirrors Available
Ultrafast-Enhanced Silver Laser Mirrors Ultrafast-Enhanced Silver Laser Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
UltraFast Innovations (UFI) 45&deg; AOI Ultrafast Chirped Mirrors UltraFast Innovations (UFI) 45° AOI Ultrafast Chirped Mirrors
  • High Reflectivity and Negative Group Delay Dispersion (GDD)
  • Ideal for Dispersion Compensation and Beam Compression @ 45° AOI
  • Designs for Femtosecond Lasers, Including Ti:sapphire
UltraFast Innovations (UFI) 1030nm Highly-Dispersive Broadband Ultrafast Mirrors UltraFast Innovations (UFI) 1030nm Highly-Dispersive Broadband Ultrafast Mirrors
  • Negative GDD of -200 fs2 at 5° AOI
  • >99.8% Reflection (p-polarization) between 950 - 1120nm
  • Designed for Pulse Compression of Yb:doped Fiber Lasers
  • Broadband Ultrafast Chirped Coating
Precision Spherical Ultraviolet (UV) Mirrors Precision Spherical Ultraviolet (UV) Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • 120nm and 190nm Design Wavelengths
  • Ideal for Focusing VUV or DUV Light
  • Broadband Reflectivity through the Visible and IR
  • Also Available as Precision Flat Mirrors
UltraFast Innovations (UFI) 2μm Highly-Dispersive Broadband Ultrafast Mirrors UltraFast Innovations (UFI) 2μm Highly-Dispersive Broadband Ultrafast Mirrors
  • Reflectivity >99.9% Between 2000 - 2200nm
  • GDD of -1000fs2 @ 5° AOI
  • Ideal for <100fs Pulse Compression of Thulium and Holmium Lasers
  • Broadband Ultrafast Chirped Coating

Broadband Dielectric &lambda;/10 Mirrors Broadband Dielectric λ/10 Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
New
  • Enhanced Reflectivity and LIDT over Metallic Coatings
  • Average Reflectivity >99% Over Broad UV, Visible, and NIR Wavelengths
  • Designed for all Polarization States from 0 – 45° AOI
Precision Ultraviolet Mirrors Precision Ultraviolet Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • 120nm and 190nm Design Wavelengths
  • Average Reflectivity >85% Across Specified Range
  • Enhanced Metallic Coatings for Broadband Reflectivity through the Visible Region
Precision Broadband Laser Mirrors Precision Broadband Laser Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • Ideal for Tunable Lasers and Reflecting Multiple Laser Sources
  • High Reflectivity from 0 - 45° for All Polarization States
  • Variety of Coating Options Available
Knife-Edge Pickoff Mirrors Knife-Edge Pickoff Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • Designed to Separate Two Beams Propagating Closely Next to Each Other
  • 45° Bevel
  • Coating Aperture Up to the Knife-Edge
  • Enhanced Aluminum, Protected Gold and Protected Silver Coating Options
Broadband Dielectric Coated Right Angle Mirrors Broadband Dielectric Coated Right Angle Mirrors
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

Broadband Laser Mirrors provide high reflectivity over a broad range of wavelengths, optimizing versatility for laser systems with multiple lasers, unusual wavelengths, or tunable laser sources. These mirrors are coated with either dielectric coatings covering most dye, diode, Ti:sapphire, Nd:YAG, and fiber laser sources or metallic coatings for applications requiring a more expansive reflectivity range. Broadband Laser Mirrors feature high surface quality and thermally-stable fused silica substrates, minimizing both scattering and thermal effects when used with lasers.

Edmund Optics offers flat Broadband Laser Mirrors with angles of incidence from 0 o to 45o, as well as specialty options for applications from the UV to the IR. TECHSPEC Broadband Dielectric Laser Mirrors are available in UV, VIS, and NIR versions with >98% reflectivity at their design wavelength range. Broadband Dielectric Coated Right Angle Mirrors are offered with similar performance for easy mounting integration into laser systems. For Deep UV (DUV) and Vacuum UV (VUV) applications, Precision Ultraviolet Mirrors provide excellent reflection with aluminum-based coatings to minimize sensitivity to polarization. Knife-Edge Pickoff Mirrors coated with enhanced aluminum, protected gold, or protected silver are also available for separating closely propagating laser beams.

×
