35mm, f/8 Ci Series Fixed Focal Length Lens

Product Description

These compact lenses are designed specifically for volume integration into applications such as analytical medical devices, including benchtop-based blood analyzers. For customized f/# versions to best suit your instrumentation application needs and to discuss volume requirements, please contact us.

Product Family Description

• Up to 2/3", C-Mount Lens
• Up to 7.5 MegaPixels, 2.8µm Pixel Size Sensors
• Instrumentation (Ci) Versions of our C Series Lenses with Streamlined Mechanical Designs and Fixed Apertures
• 3.5mm to 50mm Focal Length
• Ruggedized (Cr) Designs Also Available

Our TECHSPEC® Ci Series Fixed Focal Length Lenses are a streamlined version of our C Series Fixed Focal Length Lenses. They feature the same low lens-to-lens variation and broadband anti-reflection (BBAR) coating for maximum light transmission, while offering reduced weight and size. An adjustable, lockable focus allows for setting and locking the best focus position for instrumentation integration. The Ci Series offers a wide range of aperture options, ensuring maximum flexibility of resolution, throughput, and depth of field. These compact lenses are designed specifically for volume integration into applications such as factory inspection and automation to benchtop biomedical devices.

Edmund Optics has created a family of high performance optical designs (the C Series family) and developed 6 customized optomechanical solutions targeted for specific applications. These lens sub-families utilize the same optics as the C Series lenses providing the same optical performance in a variety of optomechanical solutions to meet your application requirements:

• C Series: Features locking cam focus and iris adjustment and is the most adjustable version of these optical designs; they are the typical high quality machine vision lenses. Also available with a VIS-NIR Broadband Anti-Reflection (BBAR) Coating.
• Ci Series: Simplified mechanics featuring fixed apertures with compact housing. Industrial Ruggedization for reduced size, cost, and locked focus.
• Cr Series: All optics glued in place and a locking C-clamp focus ring. Stabilized Ruggedization for reduced pixel shift and improved focus stability.
• Cx Series: Modular, flexible mechanics allows lenses to be taken apart for easy integration of accessories such as liquid lenses, apertures, and more.
• Liquid Lens Cx Series: Designed with an integrated liquid lens for quick autofocus.
• Cw Series: Waterproof, designed to meet IEC Ingress Protection Code IPX7 and IPX9K.
