Name: 1350nm 25.0mm Diameter, OD 2.0 Longpass Filter
Brand: TECHSPEC
SKU: 84-675
Price: ₹11,560.00

Diameter (mm):

25.00 +0.00/-0.20

Angle of Incidence (°):

Optical Density OD (Average):

≥2.0

Cut-On Wavelength (nm):

1350.00

Fused Silica (Corning 7980)

Coating:

Traditional Coated

Rejection Wavelength (nm):

1055 - 1295

Surface Quality:

40-20

Thickness (mm):

3.00

Thickness Tolerance (mm):

±0.1

Transmission (%):

>85

Transmission Wavelength (nm):

1390 - 2000

Type:

Longpass Filter

Clear Aperture (%):

Transmitted Wavefront, P-V:

λ/4

Cut-On Tolerance (%):

±2

Slope Factor (%):

3.00

Coating Specification:

Surface 1: Multi-Layer Dielectric
Surface 2: MgF₂

Wavelength Range (nm):

1055 - 2000

Regulatory Compliance

RoHS 2015:

Compliant

Reach 224:

Compliant

Certificate of Conformance:

View

Product Family Description

Sharp Cut-On Wavelength
High Rejection/Transmission Efficiency
Precision Fused Silica Substrate
Variety of OD 2.0 Longpass Filter Kits are Available

Our TECHSPEC® OD 2.0 Longpass filters are designed to have a sharp transition from reflection to transmission, making them ideal for various applications. Available in a variety of cut-on wavelengths, these filters are designed for fluorescence and order sorting applications. Eliminate stray light by creating custom bandpass filters when combined with our TECHSPEC® OD 2.0 Shortpass Filters. A single layer AR coating on the back surface enhances the overall efficiency of each filter.

Note: Due to supply chain issues, our kits may be delivered with an alternative packaging solution in place of a wooden box. For any questions, please contact [email protected].
