Name: 5.0A High Precision Laser Diode Driver
SKU: 84-357
Price: ₹34,000.00

5.0A High Precision Laser Diode Driver

Stock #84-357 Clearance

- +

₹34,000.00

Qty 1+
₹34,000.00

Volume Pricing
Request Quote

+ Add to Saved List

Compare

Get Product Downloads

Model Number:

PLD5K-CH

Operating Temperature (°C):

-40 to +85

Voltage (V):

5.0 - 30.0

Storage Temperature (°C):

-65 to +150

Rise Time (μs):

10.00

Output Current (mA):

5000.00

Power Dissipation (W):

<40

Fall Time (μs):

10.00

Current Stability, 24h @ 25°C (ppm):

<200

Power Stability, 24h @ 25°C (%):

<0.05

Regulatory Compliance

Reach 181:

Compliant

RoHS 2015:

Compliant

Certificate of Conformance:

View

Product Family Description

Up to 10A Output Current
Supports Constant Power or Constant Current Operating Modes
Compact Design for Easy System Integration

High Precision Laser Diode Drivers are ultra-stable, general purpose analog-hybrid circuits designed for use with a wide variety of laser diodes. The drivers can be configured to operate in either constant current or constant power modes. Combined with the evaluation board, High Precision Laser Diode Drivers can be used for controlling and testing a wide variety of laser diodes. A thermal kit including a heat sink and fan is recommended for current requirements greater than 500mA. Two or more drivers can be coupled together to power laser diodes requiring higher current.

Note: Shipping restrictions apply. Products cannot be shipped to Australia or Israel. Please contact us for suitable replacements.
