λ/20 High Power Laser Line Windows

Uncoated λ/20 Fused Silica Window

×
  • R < 0.25% for 266nm, 355nm, 532nm or 1064nm
  • Low Auto-Fluorescence
  • Damage Thresholds up to 10 J/cm2 @ 10ns @ 1064nm

TECHSPEC® λ/20 High Power Laser Line Windows features a high efficiency, high damage threshold V-coating to maximize transmission at the design wavelength. Damage thresholds ranging from 2 - 10J/cm2 allow easy integration into most Nd:YAG laser systems. The coating is deposited on a precision excimer grade UV grade fused silica substrate for excellent thermal stability, low wavefront distortion, and ultra-low auto-fluorescence. TECHSPEC® λ/20 High Power Laser Line Windows are available in diameters ranging from 5 to 50mm.. For custom options or wedged versions, please contact our Sales Department.

Laser Optics

Common Specifications

Thickness (mm):
3.00 ±0.10
Bevel:
Protective as needed
Clear Aperture (%):
90
Edges:
Fine Ground
Parallelism (arcsec):
≤5
Poisson's Ratio:
0.16
Young's Modulus (GPa):
73
Knoop Hardness (kg/mm2):
522
Angle of Incidence (°):
0
Substrate:
Fused Silica Excimer Grade (Corning 7980 KrF)
Index of Refraction (nd):
1.458
Surface Quality:
10-5
Transmitted Wavefront, P-V:
λ/20
Abbe Number (vd):
67.8
Density (g/cm3):
2.20
Coefficient of Thermal Expansion CTE (10-6/°C):
0.52 (+5 to +35°C)
0.57 (0 to +200°C)
0.48 (-100 to +200°C)
Fused Silica Grade:
7980 KrF 0A

Products

 Coating  Dia. (mm)  Thickness (mm)  DWL (nm)  Compare   Stock Number   Price  Buy
Uncoated 5.00 3.00 - #65-850 ₹9,169 Qty 6+ ₹8,435   Request Quote
  • 10 to 12 days
    ×

Uncoated 10.00 3.00 - #65-855 ₹9,169 Qty 6+ ₹8,435   Request Quote
  • 10 to 12 days
    ×

Uncoated 20.00 3.00 - #65-860 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Uncoated 50.00 3.00 - #65-865 ₹18,338 Qty 6+ ₹16,504   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (266nm) 5.00 3.00 266 #65-851 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (266nm) 10.00 3.00 266 #65-856 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (266nm) 20.00 3.00 266 #65-861 ₹11,003 Qty 6+ ₹9,902   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (266nm) 50.00 3.00 266 #65-866 ₹21,272 Qty 6+ ₹19,071   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (355nm) 5.00 3.00 355 #65-852 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (355nm) 10.00 3.00 355 #65-857 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (355nm) 20.00 3.00 355 #65-862 ₹11,003 Qty 6+ ₹9,902   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (355nm) 50.00 3.00 355 #65-867 ₹21,272 Qty 6+ ₹19,071   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (532nm) 5.00 3.00 532 #65-853 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (532nm) 10.00 3.00 532 #65-858 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (532nm) 20.00 3.00 532 #65-863 ₹11,003 Qty 6+ ₹9,902   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (532nm) 50.00 3.00 532 #65-868 ₹21,272 Qty 6+ ₹19,071   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (1064nm) 5.00 3.00 1064 #65-854 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (1064nm) 10.00 3.00 1064 #65-859 ₹10,269 Qty 6+ ₹9,169   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (1064nm) 20.00 3.00 1064 #65-864 ₹11,003 Qty 6+ ₹9,902   Request Quote
  • 10 to 12 days
    ×

Laser V-Coat (1064nm) 50.00 3.00 1064 #65-869 ₹21,272 Qty 6+ ₹19,071   Request Quote
  • 10 to 12 days
    ×
